SMSL M10 USB DAC & Headphone amplifier Full balanced AK4497 PCM32bit/768kHz DSD512 High Resolution 2*TPA6120A2+5*OPA1612 Decoder

Product Code : SMSL M10

Original Price : US$

My Price : US$ 544.99

Product Weight : 3.500KG

Description & Specs
Item specifics
  • Brand Name: S.M.S.L
  • DSD Sampling Frequencies: 2.8224 MHz (DSD64),22.5792 MHz (DSD512),11.2896 MHz (DSD256),5.6448 MHz (DSD128)
  • Inputs: Coaxial,Optical (SPDIF),USB Type-B,USB Type-A
  • PCM Word Length: 16-bit,32-bit,24-bit
  • Outputs: XLR,RCA,Balanced Out,6.5 mm
  • USB Compatibility: IOS,Windows 8,Windows 10,Windows 7,Windows 8.1
  • PCM Sampling Frequencies: 88.2 kHz,48 kHz,705.6 kHz,352.8 kHz,96 kHz,768 kHz,176.4 kHz,192 kHz,44.1 kHz,384 kHz
  • Type: Desktop
  • Bluetooth: No
  • Dimensions (W x H x D): 250*205*50mm
  • WIFI: No
  • Material: Metal
  • D/A Converter: AK4497
  • Model Number: M10
Product Description

New arrival SMSL M10 High Resolution AK4497 PCM32bit/768kHz DSD512 Full balanced USB DAC & Headphone amplifier 2*TPA6120A2+5*OPA1612   Decoder



Pleae note:  Bundle 1  ( Voltage: 110V-120V )

                       Bundle 2 ( Voltage: 220V-240V )



Technical parameters:

Input: USB / optical / Coaxial
Output: XRL / RCA / 6.35mm
Dynamic range: 123dB
SNR: 116dB
THD + N: 0.0004%(RCA) / 0.0001%(AMP)
USB transmission: desynchronization
USB compatibility: windows XP / 7/8 / 8,1 / 10, Mac OSX 10.6 or later, Linux
Bit depth: USB (16bit / 24bit / 32bit / 1bit )
                optical / Coaxial (16bit / 24bit)
Sampling Frequency:
         USB DSD: 2.8224 / 5.6448 / 11.2896 / 22.5792 MHz
         USB PCM: 44.1 / 48 / 88.2 / 96 / 176.4 / 192 / 352.8 / 384 / 705.6 / 768 kHz
Optical / Coaxial: 32~192 kHz
XLR output: 4Vrms
RCA output: 2 Vrms
Headphone output power:
     balanced: 340mW(32Ohm)/ 266mW(64Ohm)154mW(150Ohm)/ 87mW(300Ohm)
     un-balanced: 135mW(32Ohm)/ 90mW(64Ohm)40mW(150Ohm)/22mW(300Ohm)

Power consumption: 9W
Standby power: 0.8 W
Voltage: 110V-120V
               220V-240V
Net weight: 3 kg
Size: 250x205x50mm
Accessories: power line, remote control, USB cable, user instruction
